Overview of the MJF Technology
The Multi Jet Fusion (MJF) 3D printing process is a state-of-the art powder-based printing technology. The MJF process
produces high-quality, functional parts and is ideal for manufacturing prototypes and end use products.
Multiple inkjet arrays pass over a build plate, depositing a fusing agent and a detailing agent onto each 80 µm layer of powder. High heat then melts the powder where the fusing agent is applied, allowing for parts with complex geometries with fine details to be manufactured. The MJF platform provides a build space of 380 × 284 × 380 mm, where unfused powder supports other parts as they are printed, eliminating the need for any support material. The printer can manufacture multiple parts at once, making it an efficient process for volume production. The final parts are strong, durable, and biocompatible for skin contact, making this technology a great option for the prosthetics and orthotics field.
Technical Specifications
Average Lead Time: 3-5 Business Days
Build Space: 380 x 284 x 380 mm
Layer Thickness: 80 µm
Print Resolution: 1200 dpi
Part Accuracy: ±0.3%, lower limit of ±0.3 mm
Material Properties
PA 12 (Polyamide 12)
PA 12 is a robust thermoplastic that can produce high-density, strong and complex parts. It can withstand high levels of stress and strain making it a good choice for producing parts that need to withstand heavy loads, impacts, or wear and tear. It provides excellent chemical resistance and it’s biocompatibility certifications meet USP Class I-VI and US FDA guidance for skin surface devices.
|
Bulk Density of Powder |
0.425 g/cm 2 (ASTM D1895) |
|
Density of Parts |
1.01 g/cm 3 (ASTM D792) |
|
Tensile Strength |
48 MPa (ASTM D638) |
|
Tensile Modulus |
1800 MPa (ASTM D638) |
|
Elongation at Break |
20% (ASTM D638) |
|
Flexural Strength |
70 MPa (ASTM D790) |
|
Izod Impact notched |
3.5 kJ/m2(ASTM D256, A) |
|
Heat deflection temperature (@1.82 MPa, 264 psi) |
95ºC (ASTM D648) |
Other Industries
Due to the freedom of design and the versatility of the MJF 3D printing technology,
the final parts are well suited for many industries, including:
Aerospace
Architecture
Automotive
Consumer goods
Dental
Education
Healthcare and Medical
Industrial Manufacturing
Students
Are you a university student that is working on a project in healthcare and/or biomedical engineering?
If so, tell us about your project and you may qualify for a student discount on HP MJF prints.
